8C1021-Z

8C1021-Z is listed in the Toggle Switches range at ChipApex. The manufacturer field lists Nidec Components Corporation. Its product description is SWITCH TOGGLE SPDT 6A 125V. Review the specifications below when checking this part for your BOM.

Toggle Switches specifications for 8C1021-Z

• Description：SWITCH TOGGLE SPDT 6A 125V
• Series：8C
• Mfr：Nidec Components Corporation
• Package：Bulk
• Mounting Type：Panel Mount
• Circuit：SPDT
• Switch Function：On-Off-On
• Current Rating (Amps)：6A (AC), 4A (DC)
• Voltage Rating - AC：125 V
• Voltage Rating - DC：30 V
• Actuator Type：Flat Anti-Rotation
• Actuator Length：11.40mm
• Illumination：Non-Illuminated
• Illumination Type, Color：-
• Illumination Voltage (Nominal)：-
• Termination Style：Solder Lug
• Panel Cutout Dimensions：Circular - 6.50mm Dia
• Bushing Thread：1/4-40
• Ingress Protection：-
• Features：Sealed - Flux Protection
• Operating Temperature：-30°C ~ 85°C

Toggle Switches datasheet and documents for 8C1021-Z
