8N-24.000MDE-T

Oscillators Overview

The 8N-24.000MDE-T is a standard clock oscillator manufactured by TXC Corporation, operating at a frequency of 24 MHz. It utilizes CMOS output format and functions with a supply voltage of 1.8 V. The component features a frequency stability of +/-50 ppm across an operating temperature range of -40°C to +85°C. It is housed in a compact 2.0 mm x 1.6 mm surface-mount package designed for low electromagnetic interference applications.

Oscillators Feature Summary

• CMOS output interface compatible with digital logic circuits
• Low electromagnetic interference design for signal integrity
• Integrated enable/disable control functionality
• Wide industrial temperature range operation

Oscillators Applications

• Embedded system clock generation
• Communication interface timing
• Microcontroller clock sources
• Digital signal processing circuits

Oscillators Procurement Notes

Verify the specific ordering suffix and manufacturer part number against official TXC documentation to ensure compatibility with system requirements. Confirm availability status as distribution channels may vary. Check RoHS compliance details if environmental regulations apply to the target assembly process.

Oscillators Selection Notes

Select this component when a 24 MHz clock source with 1.8 V operation is required. Ensure the PCB layout supports the 2.0x1.6 mm SMD footprint. Verify that the +/-50 ppm stability meets the timing tolerance of the connected load circuitry within the specified temperature range.

Oscillators Part Context

This oscillator belongs to the TXC 8N series of standard quartz oscillators. The series provides various frequency options in a small form factor suitable for space-constrained electronic designs. It serves as a precise timing reference for synchronous digital systems requiring stable clock signals.

Oscillators Replacement Considerations

Direct substitutes must match the 24 MHz frequency, 1.8 V supply, CMOS output, and 2.0x1.6 mm package dimensions. Verify equivalent stability and temperature range specifications before integration.
