8Q-38.400MAAQ-T

Crystals Overview

The FTS 8Q-38.400MAAQ-T is a surface-mount MHz crystal resonator with a nominal frequency of 38.400 MHz. It utilizes fundamental operating mode and features a compact 1.60mm x 1.20mm package dimension. The component supports a load capacitance of 10pF and operates within a temperature range of -20°C to 70°C. Frequency stability is specified at 30ppm, with equivalent aging parameters also rated at 30ppm. This device is designed for applications requiring precise timing signals in space-constrained electronic assemblies.

Crystals Feature Summary

• Surface mount configuration for automated assembly
• Fundamental mode operation for stable frequency generation
• Compact 1.6x1.2 mm footprint for dense PCB layouts

Crystals Applications

• Clock signal generation for microcontrollers
• Timing reference for communication interfaces
• Frequency synthesis in consumer electronics

Crystals Procurement Notes

Verify the specific datasheet version from FTS to confirm RoHS compliance status and exact tolerance specifications. Ensure the ordering suffix matches the required packaging format. Cross-reference the load capacitance requirements with the target circuit design to guarantee accurate oscillation performance. Confirm the operating temperature range aligns with the environmental conditions of the end application.

Crystals Selection Notes

Select this component when a 38.400 MHz fundamental frequency is required in a small surface-mount package. The 10pF load capacitance specification must match the oscillator circuit design. Consider the -20°C to 70°C operating range for standard commercial applications. The 30ppm stability rating suits general timing needs rather than high-precision metrology.

Crystals Part Context

This part belongs to the FTS 8Q series of miniature crystals. The series offers various frequencies in a standardized 1.6x1.2mm outline. These components are commonly used in portable devices where board space is limited. The 8Q designation indicates the specific package style and mounting type.

Crystals Replacement Considerations

Direct substitutes include other manufacturers offering 38.400 MHz crystals in 1.6x1.2mm SMD packages with 10pF load capacitance. Verify pin compatibility and electrical characteristics before substitution. Equivalent parts must meet or exceed the 30ppm stability requirement.
