8Z-24.000MAHL-T

Crystals Overview

The TXC Corporation 8Z-24.000MAHL-T is a surface-mount quartz crystal resonator operating at a nominal frequency of 24.000 MHz. It utilizes a 2.5 x 2.0 mm seam seal package, offering a compact footprint suitable for space-constrained designs. The component features a load capacitance of 22 pF and maintains a frequency tolerance of ±30 ppm. It is rated for an industrial operating temperature range from -40°C to +85°C, ensuring reliable performance in demanding environments.

Crystals Feature Summary

• Compact 2.5x2.0mm seam seal package design
• Industrial grade temperature stability
• RoHS compliant construction

Crystals Applications

• Industrial edge gateways
• IoT communication modules
• Microcontroller clock sources

Crystals Procurement Notes

Verify the specific suffix and version against official datasheets before procurement. Ensure compatibility with the target circuit's load capacitance requirements. Confirm that the component meets all necessary environmental certifications for the intended deployment region. Cross-reference part numbers to avoid confusion with similar series variants.

Crystals Selection Notes

Select this component when a small form factor is required alongside standard industrial temperature ranges. The 22pF load capacitance dictates specific external capacitor values for circuit matching. Consider the ±30ppm stability limit for applications requiring moderate timing precision without active compensation.

Crystals Part Context

This model belongs to the 8Z series of quartz crystals manufactured by TXC Corporation. The series is characterized by its use of seam sealing technology to protect the internal quartz element. These components are designed as direct replacements for larger traditional packages while maintaining electrical equivalence.

Crystals Replacement Considerations

Public confirmed substitute part numbers: 8Z-24.000MEEV-T.
