9-146305-0-27

Headers, Male Pins Overview

The TE Connectivity AMP Connectors part number 9-146305-0-27 is a rectangular connector header belonging to the AMPMODU Mod II series. It features a right-angle, through-hole mounting style with a single row of six positions and a 0.100-inch (2.54mm) mating pitch. The connector utilizes square male pin contacts with gold plating on the mating interface and tin plating on the tail for soldering. Constructed from black thermoplastic glass-filled insulation rated UL94 V-0, it supports a maximum current rating of 3A and operates within a temperature range of -65°C to 105°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole design for board-to-board or cable connections
• Gold-plated mating contacts ensuring reliable signal transmission
• UL94 V-0 rated black thermoplastic insulation for fire safety

Headers, Male Pins Applications

• General electronic equipment interconnections
• Industrial control system circuit boards
• Consumer electronics internal wiring

Headers, Male Pins Procurement Notes

Verify the specific suffix '-27' against official TE Connectivity documentation to confirm packaging details and compliance status. Confirm availability as this component may be discontinued or subject to long lead times. Ensure compatibility with mating sockets regarding contact geometry and locking mechanisms before procurement.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle header is required for dense PCB layouts. The 2.54mm pitch is standard for general-purpose applications. Consider the 3A current rating and operating temperature limits to ensure suitability for the target electrical environment and mechanical constraints.

Headers, Male Pins Part Context

This connector is part of the AMPMODU Mod II family, a widely used line of rectangular connectors known for their versatility in various industrial and commercial applications. The series offers multiple configurations including straight and right-angle headers, sockets, and various pin counts to support diverse interconnection needs.

Headers, Male Pins Replacement Considerations

Direct substitutes include other AMPMODU Mod II headers with identical 6-position, right-angle specifications. Verify that any replacement maintains the same 2.54mm pitch, contact plating, and insulation material ratings to ensure mechanical and electrical compatibility.
