91596-104TRLF

Headers, Receptacles, Female Sockets Overview

The Amphenol ICC (FCI) part number 91596-104TRLF is a Minitek series receptacle connector designed for surface mount applications. It features a 4-position configuration with female socket contacts and a 2.00mm pitch. The connector utilizes gold plating on the contact interfaces to ensure reliable signal transmission. It is constructed with a black thermoplastic insulator rated for UL94 V-0 flammability. The component supports board-to-board or cable connections, operating within a temperature range of -55°C to 125°C.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount receptacle design with bottom entry orientation
• Gold-plated female socket contacts for enhanced conductivity
• Black thermoplastic housing with UL94 V-0 fire rating
• Push-pull locking mechanism for secure mating

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnections
• Cable-to-board connections
• High-density electronic assemblies requiring push-pull retention

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm packaging type and tape-and-reel specifications. Ensure the selected variant matches the required contact count and termination style for your PCB layout. Cross-reference the RoHS compliance status and material declarations with the latest product documentation before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, surface-mount solution with positive locking is required. The 2.00mm pitch allows for compact circuit designs while maintaining adequate spacing. Consider the thermal operating limits and voltage ratings to ensure compatibility with the system's electrical environment and mechanical constraints.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Minitek 2.00mm series, which provides high-density interconnect solutions. The series is characterized by its small form factor and robust mechanical retention systems. It serves as a standard option for modern electronics where space efficiency and reliable connection integrity are critical design parameters.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official substitution guides for compatible alternatives within the same series. Verify that any replacement maintains identical pitch, contact configuration, and mounting characteristics.
