91614-320LF

Headers, Receptacles, Female Sockets Overview

The Amphenol ICC (FCI) 91614-320LF is a Dubox series board-to-board connector featuring a 5-position female socket configuration. It utilizes a 0.100-inch (2.54mm) pitch and supports surface mount termination for vertical installation. The contacts are constructed from phosphor bronze with gold plating, while the housing is made of gray thermoplastic reinforced with glass fiber. This component operates within a temperature range of -55°C to 105°C and meets UL94 V-0 flammability standards.

Headers, Receptacles, Female Sockets Feature Summary

• Provides reliable electrical interconnection through gold-plated phosphor bronze contacts
• Features a robust thermoplastic housing reinforced with glass fiber for structural integrity
• Supports surface mount technology for automated PCB assembly processes

Headers, Receptacles, Female Sockets Applications

• Automotive electronic systems
• Industrial control equipment
• Telecommunications infrastructure

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number suffix indicates lead-free compliance when sourcing replacements. Confirm current manufacturing status as previous iterations may be obsolete. Ensure compatibility with standard surface mount reflow profiles during integration planning.

Headers, Receptacles, Female Sockets Selection Notes

Select this component for applications requiring a 2.54mm pitch in compact board-to-board layouts. Consider the vertical orientation and surface mount style for space-constrained designs. Validate thermal resistance against operating environment requirements.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Dubox family of rectangular connectors designed for high-density interconnect solutions. The series offers various pin counts and mounting styles to support diverse electronic assembly needs across multiple industries.

Headers, Receptacles, Female Sockets Replacement Considerations

Direct equivalent replacement is available under the designation 91614-320LF. Verify mechanical footprint compatibility before substitution.
