91615-317ALF

91615-317ALF is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Amphenol ICC (FCI). Its product description is CONN RCPT 34POS 0.1 GOLD SMD. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for 91615-317ALF

• Description：CONN RCPT 34POS 0.1 GOLD SMD
• Series：Dubox™
• Mfr：Amphenol ICC (FCI)
• Package：Tape & Reel (TR)
• Connector Type：Receptacle, Bottom or Top Entry
• Contact Type：Female Socket
• Style：Board to Board
• Number of Positions：34
• Number of Positions Loaded：All
• Pitch - Mating：0.100" (2.54mm)
• Number of Rows：2
• Row Spacing - Mating：0.100" (2.54mm)
• Mounting Type：Surface Mount
• Termination：Solder
• Fastening Type：Push-Pull
• Contact Finish - Mating：Gold
• Contact Finish Thickness - Mating：30.0µin (0.76µm)
• Insulation Color：Gray
• Insulation Height：0.275" (6.99mm)
• Contact Length - Post：-
• Operating Temperature：-
• Material Flammability Rating：UL94 V-0
• Contact Finish - Post：Tin
• Mated Stacking Heights：10.81mm
• Ingress Protection：-
• Features：Board Lock, Pick and Place
• Current Rating (Amps)：-
• Voltage Rating：-
