9185645904

Headers, Male Pins Overview

The HARTING 09185645904 is a SEK 18 series vertical header connector designed for board-to-wire applications. It features 64 positions arranged in a dual-row configuration with a 2.54mm pitch. The component utilizes through-hole termination and gold-plated contacts to ensure reliable signal transmission. Constructed with a gray PBT insulator reinforced with glass fiber, it meets UL94 V-0 flammability standards. This connector supports a wide operating temperature range from -55°C to 125°C.

Headers, Male Pins Feature Summary

• Dual-row layout providing high-density connectivity within a compact footprint
• Gold-plated contact surfaces ensuring stable electrical performance and corrosion resistance
• Integrated keying slots and mounting flanges for precise alignment and secure PCB attachment

Headers, Male Pins Applications

• Industrial automation control systems
• Communication equipment interfaces
• Railway signaling and power distribution units

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official HARTING documentation to confirm exact pin count, insulation color, and termination style. Ensure compatibility with mating sockets regarding keying options and mechanical retention requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when high-density interconnection is required for industrial environments. The SEK 18 series offers robust mechanical stability and verified thermal performance suitable for demanding operational conditions compared to standard consumer-grade connectors.

Headers, Male Pins Part Context

This part belongs to the HARTING SEK 18 family of micro-connectors. The series is engineered for space-constrained applications requiring reliable signal integrity. It complements other SEK components like sockets and IDC cables to form complete interconnect solutions.

Headers, Male Pins Replacement Considerations

Direct substitutes include variants within the same SEK 18 series such as 09185646904. Verify that replacement parts match the original pin count, row configuration, and plating specifications to maintain system compatibility.
