9185645922

Headers, Male Pins Overview

The HARTING 9185645922 is a vertical pin header connector from the SEK series, designed for through-hole mounting. It features 64 positions with a 0.100-inch (2.54mm) pitch and two rows of contacts. The male pins have gold-plated mating surfaces and tin-plated tails. The housing is constructed from glass-fiber reinforced PBT with UL94 V-0 flammability rating. Key dimensions include an insulation height of 0.681 inches (17.30mm), a total contact length of 0.713 inches (18.10mm), and a mating contact length of 0.228 inches (5.80mm).

Headers, Male Pins Feature Summary

• Vertical board-to-board or board-to-wire connection capability via through-hole termination.
• Gold-plated contact surfaces ensure reliable signal transmission and corrosion resistance.
• Short locking/popping hooks provide secure mechanical retention during assembly.
• Square-shaped male pins facilitate precise alignment within mating receptacles.

Headers, Male Pins Applications

• Industrial control systems requiring high-density signal routing.
• Automotive electronics assemblies utilizing standard 2.54mm spacing.
• Communication equipment backplanes and interface modules.
• General-purpose printed circuit board interconnections.

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm exact pin count and plating specifications. Ensure compatibility with mating connectors regarding keying and hook style. Confirm RoHS compliance status if required by project regulations. Cross-reference the full part number with authorized distributors to avoid counterfeit components.

Headers, Male Pins Selection Notes

Select this component when a 64-position vertical header is required for PCB integration. The 2.54mm pitch is standard for general electronics, while the SEK series offers robust mechanical stability. Consider the insulation height and overall profile to ensure clearance within the enclosure design. Verify that the through-hole footprint matches the manufacturing capabilities of the assembly line.

Headers, Male Pins Part Context

This connector belongs to the HARTING SEK series, which focuses on micro-connectors for dense electronic applications. The series is characterized by its reliability in industrial environments and standardized dimensions. The 9185645922 variant specifically addresses the need for higher pin counts in compact vertical configurations, supporting complex signal processing tasks.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other 64-pin, 2.54mm pitch vertical headers from manufacturers such as Molex or Samtec, provided they match the SEK series mechanical envelope and pin configuration. Verify that alternative parts support the same through-hole termination and locking mechanism requirements.
