9195346829

Headers, Receptacles, Female Sockets Overview

The HARTING 9195346829 is a SEK/IDC Low Profile straight female connector designed for board-to-board and mezzanine applications. It features a 6-pin configuration with 4.5mm press-in tails, suitable for PL2 mounting standards. The housing is constructed from Liquid Crystal Polymer (LCP), providing robust structural integrity. Electrical specifications include an insulation resistance of 1 GOhms, ensuring reliable signal transmission in industrial environments.

Headers, Receptacles, Female Sockets Feature Summary

• Low profile design optimized for space-constrained mezzanine interfaces
• IDC termination method facilitates rapid assembly without soldering
• Press-in tail technology ensures secure PCB mounting stability

Headers, Receptacles, Female Sockets Applications

• Industrial automation control systems
• Data communication equipment backplanes
• Factory automation network components

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count and tail length against the official datasheet to ensure compatibility with the target Printed Circuit Board layout. Confirm that the Liquid Crystal Polymer housing material meets the thermal requirements of the intended operating environment before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when low-profile interconnects are required for high-density board stacking. The IDC termination style offers advantages in production speed compared to traditional soldering methods. Ensure the PL2 mounting standard aligns with the system's mechanical constraints and that the 6-pin capacity suffices for the signal routing needs.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the HARTING SEK series, which specializes in low-profile connectors for demanding industrial applications. The series supports various pin counts and termination styles, allowing for flexible system integration. HARTING designs these components to meet rigorous standards for reliability and performance in factory automation and networking sectors.

Headers, Receptacles, Female Sockets Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify cross-compatibility with other HARTING SEK variants based on mechanical footprint and electrical ratings before considering alternatives.
