920-0198-01

Headers, Male Pins Overview

The SchmartBoard 920-0198-01 is a dual-row male header connector assembly designed for electronic prototyping. It consists of four individual 2x20 pin headers, providing a total of 40 positions per unit with a standard 2.54mm (0.1 inch) pitch. The components are manufactured for vertical through-hole mounting on printed circuit boards. This configuration supports the physical connection of circuit blocks within the SchmartBoard prototyping system, facilitating the integration of surface mount and through-hole technologies.

Headers, Male Pins Feature Summary

• Provides four separate 2x20 male header units for modular circuit block interconnection
• Features vertical orientation suitable for standard through-hole PCB mounting techniques
• Utilizes a 2.54mm pitch to ensure compatibility with standard breadboard and prototyping grid systems

Headers, Male Pins Applications

• Interconnecting discrete circuit blocks in multi-stage electronic prototypes
• Facilitating hand-soldering workflows for surface mount component evaluation
• Creating physical links between test sections in complex development kits

Headers, Male Pins Procurement Notes

Verify that the received package contains exactly four distinct 2x20 header units as specified by the product designation. Confirm the part number matches 920-0198-01 to ensure correct quantity and spacing specifications. Inspect pins for straightness and housing integrity prior to installation. Cross-reference the manufacturer documentation to confirm compatibility with your specific prototyping board layout requirements.

Headers, Male Pins Selection Notes

Select this component when a modular approach to circuit prototyping is required, allowing for individual testing of sub-circuits before final assembly. The dual-row format is appropriate for applications requiring dense pin access in a vertical profile. Consider the 40-position capacity relative to the signal count needed for each connected block. Ensure the target PCB has sufficient space for four separate header placements along the 2.54mm grid.

Headers, Male Pins Part Context

This part belongs to the SchmartBoard accessory family, which specializes in prototyping aids for advanced chip technologies. The system enables users to work on one circuit block at a time, test individually, and then physically connect them. These headers are integral to the workflow that simplifies hand soldering of surface mount components compared to traditional through-hole methods.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Users should verify mechanical fit and electrical continuity if sourcing generic equivalents. Ensure any alternative maintains the 2.54mm pitch and dual-row 2x20 configuration to preserve compatibility with the existing prototyping infrastructure.
