929400-01-08

Headers, Male Pins Overview

The 3M 929400-01-08 is a vertical pin header connector from the 929 series, designed for board-to-board applications. It features eight positions with a 0.100-inch (2.54mm) pitch and utilizes through-hole termination for secure PCB mounting. The connector employs square male pins with tin-lead plating to ensure reliable mating contact. Constructed with glass-reinforced PBT insulation rated UL94 V-0, it supports operation within a temperature range of -40°C to 105°C. The unit includes push-pull locking mechanisms and measures 0.535 inches in overall contact length.

Headers, Male Pins Feature Summary

• Vertical orientation with push-pull locking mechanism for secure attachment
• Separable design allowing flexible prototype configuration and custom sizing
• Tin-lead plated square male pins for consistent mating performance
• Glass-reinforced PBT insulation providing high thermal stability

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• Industrial automation systems
• Data center infrastructure

Headers, Male Pins Procurement Notes

Verify component availability as this specific part number may be discontinued or subject to limited supply constraints. Confirm that the tin-lead plating specification aligns with current environmental compliance requirements for your target assembly process. Ensure proper handling procedures are followed during storage and installation to maintain connector integrity.

Headers, Male Pins Selection Notes

Select this connector when a vertical, separable header with push-pull retention is required for rigid board-to-board links. The 0.100-inch pitch accommodates standard PCB layouts, while the through-hole solder tails provide robust mechanical anchoring. Consider compatible mating sockets such as the 929870 or 929974 series for complete assembly solutions.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series of pin strip headers, which offer horizontal and vertical configurations. The series is characterized by its separable nature, enabling designers to customize pin counts easily. These connectors are widely utilized in electronic assemblies requiring reliable signal transmission and durable physical connections across various industrial sectors.

Headers, Male Pins Replacement Considerations

Compatible mating counterparts include the 929870-01-08-RA and 929974-01-08. Verify that substitute headers match the 0.100-inch pitch and vertical orientation. Ensure the replacement maintains the same push-pull locking style and through-hole termination method for direct interchangeability.
