929665-04-06-I

Headers, Male Pins Overview

The 3M 929665-04-06-I is a vertical pin strip header connector from the 929 series, designed for through-hole PCB mounting. It features a 12-position, 2-row configuration with a 0.100-inch (2.54mm) pitch. The connector utilizes square male pins with gold plating on both mating and tail sections, each 10.0µin thick. Constructed with black glass-reinforced PBT insulation rated UL94 V-0, it supports a maximum current of 2.5A and operates within a temperature range of -40°C to 105°C. The unit employs a push-pull locking mechanism and is currently discontinued.

Headers, Male Pins Feature Summary

• Vertical pin strip design with push-pull locking for secure board-to-board connections
• Gold-plated square male contacts ensuring reliable signal transmission
• Glass-reinforced PBT insulation providing high thermal stability and flame resistance
• Through-hole termination with solder tails optimized for wave soldering processes

Headers, Male Pins Applications

• Board-to-board interconnections in industrial control systems
• Signal routing in automated manufacturing equipment
• Data processing hardware assembly
• Telecommunications infrastructure components

Headers, Male Pins Procurement Notes

This component is officially discontinued by the manufacturer. Procurement must rely on secondary market distributors or surplus inventory providers. Verify part authenticity and physical condition carefully, as availability varies significantly across suppliers. Confirm that the specific lot matches original specifications before integration into production lines.

Headers, Male Pins Selection Notes

Engineers should evaluate alternative connectors within the 929 series that remain in active production. Consider matching socket counterparts such as the 929975 series for compatible mating interfaces. Ensure replacement options maintain identical pitch, row count, and contact material specifications to preserve mechanical fit and electrical performance in existing designs.

Headers, Male Pins Part Context

Part of the 3M 929 Pin Strip family, this connector represents a standard solution for rigid board interconnects. The series offers modular flexibility through breakaway capabilities, allowing custom length configurations. Designed for high-volume manufacturing, these headers provide consistent alignment and robust mechanical retention for dense circuit layouts.

Headers, Male Pins Replacement Considerations

Official substitutes include 929665-03-36-I for higher density requirements. Cross-reference with 929836-01-04 for single-row alternatives. Verify compatibility with mating sockets like 929852-01-06-RA.
