929665-05-34-EU

Headers, Male Pins Overview

The 3M 929665-05-34-EU is a vertical pin strip header from the 929 Series, designed for board-to-board interconnection. It features a dual-row configuration with 68 positions and a 0.100-inch (2.54mm) pitch. The connector utilizes square male pins made of copper alloy, terminated via through-hole soldering. Insulation is provided by black PCT material rated UL94 V-0, supporting an operating temperature range of -40°C to 105°C. Gold plating on contacts ensures reliable conductivity.

Headers, Male Pins Feature Summary

• Dual-row vertical header design for high-density board-to-board connections
• Square male pin contact geometry for secure mating stability
• Through-hole termination method ensuring robust mechanical fixation
• Gold-plated copper alloy contacts for enhanced corrosion resistance

Headers, Male Pins Applications

• Industrial automation control systems
• Automotive electronic manufacturing
• Consumer electronic device assembly

Headers, Male Pins Procurement Notes

Verify component authenticity against official 3M documentation due to potential supply chain variations. Confirm that the specific order matches the 68-position dual-row specification. Ensure storage conditions maintain moisture sensitivity level integrity prior to installation. Cross-reference datasheet revisions to confirm current manufacturing status and compliance certifications.

Headers, Male Pins Selection Notes

Select this component when a high-pin-count vertical interconnect is required for space-constrained applications. The dual-row layout maximizes connection density while maintaining standard 2.54mm spacing. Consider the through-hole mounting requirement for PCB design compatibility. Evaluate thermal performance within the specified -40°C to 105°C range for environmental suitability.

Headers, Male Pins Part Context

This part belongs to the 3M 929 Series, a widely recognized line of pin strip headers. The series offers various position counts and row configurations to suit diverse electronic assembly needs. The 929665-05-34-EU specifically addresses requirements for substantial I/O interfaces in compact form factors, leveraging established 3M engineering standards for reliability.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with mating connectors before considering alternative sources.
