929710-01-29-RK

$6.69

Description：CONN HEADER VERT 58POS 2.54MM
Series：929
Mfr：3M
Package：Bulk

SKU:6e04a267d9e6 Category: Headers, Male Pins Brand: 3M

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

929710-01-29-RK is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists 3M. Its product description is CONN HEADER VERT 58POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 929710-01-29-RK

Description：CONN HEADER VERT 58POS 2.54MM
Series：929
Mfr：3M
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：58
Number of Rows：2
Row Spacing - Mating：0.100" (2.54mm)
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.318" (8.08mm)
Contact Length - Post：0.110" (2.79mm)
Overall Contact Length：0.528" (13.42mm)
Insulation Height：0.100" (2.54mm)
Contact Shape：Square
Contact Finish - Mating：Tin
Contact Finish Thickness - Mating：200.0µin (5.08µm)
Contact Finish - Post：Tin
Contact Material：Copper Alloy
Insulation Material：Polycyclohexylenedimethylene Terephthalate (PCT)
Features：-
Operating Temperature：-40°C ~ 105°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：2.5A
Voltage Rating：-

Headers, Male Pins datasheet and documents for 929710-01-29-RK

929710-01-29-RK

Headers, Male Pins Overview

The 3M 929710-01-29-RK is a vertical pin strip header from the 929 series, designed for through-hole PCB mounting. It features a 2.54 mm (0.1 inch) contact pitch and a single row of 29 positions. The connector utilizes tin-plated contacts with a nickel base material and a fiberglass-reinforced polyester (PCT) insulator. This component supports board-to-board connections and offers design flexibility through stackable and breakaway configurations.

Headers, Male Pins Feature Summary

Stackable design expands circuit board layout flexibility
Breakaway configuration allows for custom terminal counts
Solder pillars facilitate wave soldering production processes

Headers, Male Pins Applications

Board-to-board interconnections
Line-to-board connections
Industrial automation systems
Data center equipment design

Headers, Male Pins Procurement Notes

Verify that the specific part number matches the required pin count and orientation before procurement. Confirm insulation material specifications against environmental requirements. Ensure compatibility with standard wave soldering profiles as defined in J-STD-020C guidelines for reliable assembly.

Headers, Male Pins Selection Notes

Select this component when a vertical, single-row header with a 2.54 mm pitch is required. The 929 series provides options for both tin and gold plating. Consider the low-profile nature of the series if space constraints exist on the target printed circuit board.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series of pin strips and sockets. The series is characterized by its versatility in prototype and custom designs, offering both horizontal and vertical orientations. It is widely used in electronic interconnect solutions across various industrial sectors.
