929710-11-11-RK

Headers, Male Pins Overview

The 3M 929710-11-11-RK is a board-to-board connector header from the 929 series. It features a vertical through-hole design with dual rows and a 2.54 mm (0.100 inch) pitch. The component provides 22 positions, accommodating a total of 44 contacts. It utilizes tin-plated terminals for reliable electrical connection. The housing is constructed from black thermoplastic material, ensuring mechanical stability during assembly.

Headers, Male Pins Feature Summary

• Vertical dual-row header configuration for direct PCB mounting
• Standard 2.54 mm pitch for broad compatibility
• Tin-plated contact surfaces for corrosion resistance

Headers, Male Pins Applications

• Board-to-board interconnections in electronic assemblies
• Signal routing between stacked circuit boards
• General-purpose electronic device manufacturing

Headers, Male Pins Procurement Notes

Verify the specific suffix 'RK' against official 3M documentation to confirm lead time requirements and RoHS compliance status. Ensure the ordering part number matches the exact pin count and row configuration required for the target application to avoid integration errors.

Headers, Male Pins Selection Notes

Select this component when a vertical, dual-row header with a 2.54 mm pitch is required. Confirm that the 22-position capacity meets the signal or power distribution needs. Verify that the mating socket counterpart supports the same pitch and row arrangement for proper alignment.

Headers, Male Pins Part Context

This connector belongs to the 3M 929 series, which offers various configurations for board-to-board applications. Similar models in this family vary by position count, row orientation, and terminal plating options, allowing designers to choose based on space and connectivity constraints.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other 3M headers within the 929 series that share the 2.54 mm pitch and dual-row vertical format. Cross-reference the pin count and housing dimensions to ensure mechanical fit before substitution.
