929834-03-05

Headers, Male Pins Overview

The 3M 929834-03-05 is a single-row male pin header connector from the 929 series, designed for through-hole mounting. It features a 0.100-inch (2.54mm) pitch and provides three positions. The contacts are made of copper alloy with tin-lead plating on the mating section, offering a contact length of 0.235 inches (5.97mm). The housing is constructed from black PBT material reinforced with glass fiber, rated UL94 V-0 for flammability. It supports a current rating of 2.5A and operates within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• Square-shaped male pins ensure precise alignment during board-to-board connections.
• Push-pull locking mechanism secures the connector interface firmly.
• Glass-fiber reinforced PBT insulation provides structural stability and flame resistance.

Headers, Male Pins Applications

• Board-to-board interconnects in electronic assemblies
• General-purpose signal routing in industrial equipment
• Connection points in consumer electronics hardware

Headers, Male Pins Procurement Notes

Verify component authenticity by checking manufacturer markings against official datasheets. Confirm that the tin-lead contact finish matches project requirements, as RoHS compliance may vary. Inspect for physical damage to the square pins and ensure the black PBT housing is intact before installation.

Headers, Male Pins Selection Notes

Select this part when a low-profile, single-row header with a 2.54mm pitch is required. Ensure the circuit design accommodates the 2.5A current rating and the operating temperature range of -40°C to 105°C. Verify that the through-hole soldering process aligns with the specified column length and pin geometry.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series of headers and wire housings. It serves as a male pin strip variant within the broader 929834 product family, which offers various pin counts and configurations. The series is characterized by its standardized 0.100-inch spacing and robust mechanical locking features.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include 929870-01-03-RA and 929850-01-03-RA. These counterparts provide matching 3-position interfaces with compatible pitch and locking mechanisms for reliable assembly.
