929836-01-19-RK

Headers, Male Pins Overview

The 3M 929836-01-19-RK is a vertical pin strip header connector from the 929 series, designed for through-hole PCB mounting. It features a dual-row configuration with 38 positions and a 2.54mm (0.100 inch) pitch. The contacts are copper alloy with a tin plating finish. Constructed with glass-reinforced PBT insulation rated UL94 V-0, it supports operating temperatures from -40°C to 105°C. This component utilizes a push-pull locking mechanism and is intended for board-to-board interconnections.

Headers, Male Pins Feature Summary

• Dual-row pin strip design with 38 positions for high-density connections
• Push-pull locking mechanism ensures secure mating engagement
• Through-hole termination with solder pillars facilitating wave soldering processes
• Glass-reinforced PBT insulation provides thermal stability and UL94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board interconnections in industrial equipment
• Signal routing in automated manufacturing systems
• Data center infrastructure hardware assembly

Headers, Male Pins Procurement Notes

Verify RoHS compliance status as this specific part number may not meet current environmental directives. Confirm availability since distribution channels may list discontinued or obsolete stock. Ensure the tin-plated contact finish matches system requirements regarding lead-free regulations. Cross-reference the 38-position count and dual-row layout against schematic footprints to prevent mechanical mismatch during procurement.

Headers, Male Pins Selection Notes

Select this connector when a rigid, vertical header with a push-pull lock is required for dual-row applications. The 2.54mm pitch suits standard PCB spacing. Consider the tin plating for cost-effective signal transmission. Verify that the 38-position length fits the available board real estate. Ensure the operating temperature range of -40°C to 105°C aligns with the environmental conditions of the target application.

Headers, Male Pins Part Context

This component belongs to the 3M 929 Series Pin Strip connectors, which offer versatile single and dual-row options. The series supports various contact counts and plating finishes, including gold and tin. These headers are engineered for reliable performance in demanding environments, featuring robust insulation materials and standardized spacing for widespread compatibility across electronic assemblies.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are identified in the provided documentation.
