929836-02-08-RK

Headers, Male Pins Overview

The 3M 929836-02-08-RK is a dual-row pin header from the 929 series, designed for board-to-board connections. It features an 8-position configuration with a 2.54 mm (0.1 in) pitch and straight mounting orientation. The connector utilizes tin-plated copper alloy contacts rated for 2.5 A current and 1.5 kV voltage. Constructed with black PCT insulation, it supports wave or infrared soldering processes and offers optional board-end pin retention.

Headers, Male Pins Feature Summary

• Dual-row pin header design for reliable board-to-board interconnects
• High-temperature PCT insulation suitable for wave or infrared soldering
• Tin-plated copper alloy contacts ensuring stable electrical performance
• Straight mounting style with optional board-end pin retention capability

Headers, Male Pins Applications

• Board-to-board connections in industrial automation systems
• Interconnections within high-temperature data center designs
• General electronic circuit assembly requiring robust header connectors

Headers, Male Pins Procurement Notes

Verify component authenticity through authorized channels due to potential supply chain variations. Confirm RoHS compliance status as specific listings may indicate non-compliance depending on manufacturing origin. Check for obsolescence notices as this series may have limited availability. Ensure mating connector compatibility matches the 0.100 inch pitch specification before procurement.

Headers, Male Pins Selection Notes

Select this model when a dual-row, straight-mount header is required for high-temperature environments. The PCT material ensures stability during wave or infrared soldering processes. Verify that the 8-position count aligns with circuit requirements. Consider the tin plating option for cost-effective applications where gold plating is unnecessary. Ensure mechanical fit within the designated PCB footprint.

Headers, Male Pins Part Context

This component belongs to the 3M 929 series of headers and wire housings. It represents a standard solution for rectangular connector needs within the 3M Electronic Solutions Division portfolio. The series provides versatile options for single or dual-row configurations, supporting various contact counts and plating materials to meet diverse electronic assembly standards.

Headers, Male Pins Replacement Considerations

Compatible mating sockets include the 929975 series. For direct replacement, verify identical pitch, row count, and housing dimensions. Alternative part numbers within the same family may offer different pin counts but maintain mechanical compatibility.
