Headers, Male Pins Overview

The 3M 929836-03-34 is an unshrouded header connector featuring 68 positions with a 2.54 mm (0.100 inch) pitch. It utilizes a two-row configuration with male pin contacts made of copper alloy and tin-plated mating surfaces. Designed for through-hole vertical mounting, the unit employs PCT insulation rated UL94 V-0 for high-temperature resistance. The connector supports a current rating of 2.5 A and operates within a temperature range of -40°C to 105°C.

Headers, Male Pins Feature Summary

• High-temperature PCT insulation suitable for wave or infrared soldering processes
• Vertical through-hole termination for secure board-to-board connections
• Unshrouded design with square contact shape for standard header applications

Headers, Male Pins Applications

• Board-to-board interconnections in industrial equipment
• Signal routing in automated manufacturing systems
• General electronic assembly requiring high-temperature solder compatibility

Headers, Male Pins Procurement Notes

Verify component status before procurement as this specific part number may be discontinued or end-of-life. Confirm that the 68-position vertical header meets mechanical space constraints. Ensure the tin-plated contact finish aligns with system corrosion requirements. Validate that the 2.5A current rating suffices for the intended circuit load without derating issues.

Headers, Male Pins Selection Notes

Select this component when a vertical, unshrouded 2.54mm pitch header is required for high-temperature environments. The PCT material ensures stability during wave soldering. Consider the 68-position count for dense signal routing. Verify that the through-hole mounting style matches the PCB fabrication capabilities and that the copper alloy contacts provide adequate conductivity for the application.

Headers, Male Pins Part Context

This connector belongs to the 3M 929 series, a line of versatile pin strips available in single and double row configurations. The 929836 prefix indicates a specific header variant within this family. These components are engineered for robust performance in demanding electronic assemblies, offering reliable electrical connectivity across various industrial and commercial sectors.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Users should consult official 3M catalogs for direct equivalents or verify compatibility with generic 2.54mm 68-pin vertical headers if cross-brand substitution is necessary.
