929850-01-16-RA

Headers, Receptacles, Female Sockets Overview

The 929850-01-16-RA is a 16-position, single-row board-to-board header from the 3M 929 series. It features a 0.100 inch (2.54 mm) pitch and vertical through-hole mounting with solder termination. The connector utilizes gold-plated contacts on a copper alloy base with nickel plating, housed in black PBT insulation rated UL94 V-0. It supports a current rating of 1A to 2.5A and operates within -40°C to 105°C.

Headers, Receptacles, Female Sockets Feature Summary

• Fork-style terminal design facilitates stable pin retention during wave soldering processes.
• Low-profile housing structure provides secure board fixation for compact assembly applications.
• Gold-plated contact surfaces ensure reliable electrical performance and corrosion resistance.

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnections
• Industrial automation systems
• Data center hardware assemblies

Headers, Receptacles, Female Sockets Procurement Notes

Verify component authenticity against official 3M documentation prior to integration. Confirm that the specific suffix 'RA' corresponds to the required gold-plated contact configuration and straight orientation. Ensure compatibility with mating socket connectors within the same 929 series family to maintain mechanical and electrical integrity.

Headers, Receptacles, Female Sockets Selection Notes

Select this model for vertical PCB mounting requiring robust signal transmission. The fork-style terminals are optimized for wave soldering stability. Verify that the 16-pin count and 2.54mm pitch align with the target circuit layout. Consider the low-profile design for space-constrained environments requiring durable board-to-board connections.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the 3M 929 series of Pin Strip headers, designed for high-reliability electronic interconnects. The series offers various pin counts and configurations, supporting both single and double-row arrangements. These connectors are engineered for industrial and commercial electronics where consistent performance under thermal stress is critical.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible mating sockets include part numbers such as 929870-01-16-RA and 929984-01-16-RK. Ensure the replacement maintains the same 2.54mm pitch and 16-position count. Verify that the mating connector's contact plating and housing material match the system requirements for environmental durability.

Headers, Receptacles, Female Sockets FAQ

What is the recommended soldering process for this connector?

The fork-style terminal design is specifically intended to facilitate wave soldering production, ensuring stable pin retention during the manufacturing process.

What is the operating temperature range?

The connector is rated for operation between -40°C and +105°C, suitable for standard industrial electronic environments.
