94063-119HLF

Headers, Male Pins Overview

The 94063-119HLF is a Bergstik II single-row header connector manufactured by Amphenol ICC (FCI). It features a vertical through-hole mounting style with a 0.100 inch (2.54 mm) pitch. The component provides 19 positions for male pin contacts. Contact plating consists of tin over nickel, ensuring reliable electrical performance. This connector is designed for board-to-board or cable-to-board applications requiring standard spacing and durable mechanical retention.

Headers, Male Pins Feature Summary

• Vertical orientation for direct PCB insertion
• Single row configuration with 19 positions
• Tin over nickel contact finish for corrosion resistance

Headers, Male Pins Applications

• Data communication equipment interconnects
• Server and storage system backplanes
• Industrial control panel wiring

Headers, Male Pins Procurement Notes

Verify the specific revision level against the official Amphenol datasheet to ensure compatibility with existing assembly processes. Confirm that the tin over nickel plating meets the required environmental standards for the target application. Check for any recent product change notices regarding material substitutions or packaging updates before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this part when a single-row, 19-position header with a 2.54mm pitch is required. Ensure the PCB footprint matches the specified dimensions for vertical mounting. Consider the current carrying capacity and mating cycle requirements relative to the tin over nickel contact finish. Verify that the housing material and flange design align with the enclosure constraints of the final assembly.

Headers, Male Pins Part Context

This component belongs to the Bergstik II series, a widely used line of headers from Amphenol FCI. The series is known for its reliability in high-volume manufacturing environments. It supports various pin counts and orientations, making it a versatile choice for general-purpose electronic connections in commercial and industrial sectors.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 19-position count, 2.54mm pitch, and vertical mounting style. Cross-reference with other manufacturers' single-row headers using identical mechanical dimensions and contact plating specifications to ensure interchangeability without redesigning the PCB layout.
