94611-432HLF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 94611-432HLF is a BergStik unshrouded vertical header designed for board-to-board applications. It features a single row with 32 positions and a 2.54 mm pitch. The connector utilizes male pin contacts made of phosphor bronze with tin plating, rated for 3 A current. It employs through-hole solder termination with straight mounting. The housing is black thermoplastic, compliant with UL 94 V-0 flammability standards. Operating temperature ranges from -65°C to +125°C, with an insulation resistance of 5 GOhms.

Headers, Male Pins Feature Summary

• Unshrouded vertical design for compact board-to-board interconnects
• Single row configuration with 32 positions at 2.54 mm spacing
• Tin-plated phosphor bronze contacts ensuring reliable signal transmission
• Through-hole solder termination for secure PCB mounting

Headers, Male Pins Applications

• Board-to-board electrical connections
• General purpose electronic assemblies
• Industrial instrumentation interfaces

Headers, Male Pins Procurement Notes

Verify the exact position count against official datasheets, as similar part numbers in this series may vary by one or two positions. Confirm RoHS compliance status and lead-free specifications directly with the manufacturer or authorized distributors. Ensure the ordering suffix matches the required contact plating and packaging format. Cross-reference the specific revision level to guarantee compatibility with mating connectors and PCB footprint requirements.

Headers, Male Pins Selection Notes

Select this component when a low-profile, unshrouded vertical header is required for standard 2.54 mm pitch applications. The 32-position single-row layout suits dense circuit designs where shrouding is unnecessary. Consider the tin-plated contacts for general-purpose use rather than high-corrosion environments. Verify that the 3 A current rating meets the system's power distribution needs. Ensure the through-hole mounting method aligns with the assembly process capabilities.

Headers, Male Pins Part Context

This part belongs to the BergStik series by Amphenol ICC (FCI), formerly Framatome Connectors International. The series specializes in cost-effective, high-density interconnect solutions for various electronic industries. Amphenol acquired FCI, integrating its robust connector portfolio into the broader communications and industrial product lines. The 94611 series represents a standard offering for reliable, through-hole mounted headers.

Headers, Male Pins Replacement Considerations

Direct substitutes include other 32-position, 2.54 mm pitch unshrouded headers from compatible manufacturers. Verify mechanical dimensions, including overall height and pin length, to ensure PCB fit. Check electrical ratings for matching current and voltage specifications. Confirm that the contact material and plating are equivalent to prevent galvanic corrosion issues.
