95278-402B10LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 95278-402B10LF is a BergStik II header connector designed for board-to-board and mezzanine applications. It features a 2.54 mm pitch with 10 positions arranged in a dual-row configuration. The component utilizes surface mount termination with a straight installation angle. Electrical ratings include a current capacity of 3 A and a voltage rating of 1.5 kV. The contacts are tin-plated phosphor bronze, housed in thermoplastic material rated UL 94 V-0. The operating temperature range spans from -65 C to +125 C, with an insulation resistance of 5 GOhms.

Headers, Male Pins Feature Summary

• Dual-row vertical header design for compact board-to-board interconnects
• Surface mount termination ensures secure PCB attachment
• Tin-plated phosphor bronze contacts provide reliable conductivity

Headers, Male Pins Applications

• Board-to-board connections
• Mezzanine circuit interfaces
• High-density electronic assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's official datasheet to confirm contact plating, housing length, and packaging type. Ensure the selected variant matches the required thermal and electrical specifications for the target application environment before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a 2.54 mm pitch dual-row header is required for surface mount assembly. Confirm that the 3 A current rating and 1.5 kV voltage withstand capability align with system requirements. Verify compatibility with mating socket connectors within the same BergStik II series family.

Headers, Male Pins Part Context

This part belongs to the BergStik II series of headers manufactured by Amphenol FCI. The series offers various position counts and lengths to support diverse density requirements in electronic manufacturing. These connectors are widely used in industrial and commercial equipment requiring robust signal transmission.

Headers, Male Pins Replacement Considerations

Consult the official Amphenol FCI cross-reference documentation for verified substitute part numbers. Generic equivalents may not match the precise mechanical dimensions or electrical performance characteristics of the original component.
