95687-134HLF

Headers, Male Pins Overview

The 95687-134HLF is a vertical header connector manufactured by Amphenol ICC (FCI). It features a 2.54mm pitch and provides 34 positions in a single row configuration. The component utilizes through-hole termination for secure board mounting. Contact surfaces are finished with tin plating to ensure reliable electrical conductivity. The housing is constructed from thermoplastic material rated UL94 V-0 for flame resistance. This connector is designed for general signal transmission applications requiring standard spacing.

Headers, Male Pins Feature Summary

• Vertical pin arrangement for direct board insertion
• Single row layout accommodating thirty-four contacts
• Tin-plated terminals for corrosion resistance
• UL94 V-0 rated insulating housing material

Headers, Male Pins Applications

• General purpose electronic circuit interconnections
• Signal transmission between PCBs
• Industrial control system wiring
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm terminal plating and housing color options. Ensure the selected variant matches the required contact count and pitch specifications for your design. Cross-reference the part number with official Amphenol documentation to confirm availability status and compliance certifications before finalizing procurement plans.

Headers, Male Pins Selection Notes

Select this component when a vertical, single-row header with a 2.54mm pitch is required. Confirm that the through-hole mounting style aligns with the target printed circuit board layout. Verify that the 34-position capacity meets the signal line requirements of the application. Ensure the operating temperature range and voltage ratings are sufficient for the intended environment.

Headers, Male Pins Part Context

This part belongs to the FCI Basics series of connectors, which focuses on cost-effective, durable solutions for wire-to-board connections. The product line emphasizes ease of assembly and reliable performance in standard industrial environments. Amphenol ICC (FCI) designs these components to meet rigorous quality standards for mass-produced electronic devices.

Headers, Male Pins Replacement Considerations

Consult the official Amphenol cross-reference guide for verified substitute part numbers. Generic equivalents may differ in critical dimensions or material properties. Only use substitutes explicitly listed by the manufacturer to ensure mechanical and electrical compatibility.
