961129-5604-AR

Headers, Male Pins Overview

The 3M 961129-5604-AR is a single-row pin header connector from the 961 series, designed for through-hole mounting. It features 29 positions with a 2.54 mm pitch and right-angle orientation. The contacts are phosphor bronze with gold plating on the mating interface, while the tail is tin-plated. Rated for 2 A current, it operates between -55°C and +105°C. The black PBT housing meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Right-angle through-hole design for compact board integration
• Gold-plated contacts ensure reliable signal transmission
• High-temperature resistant PBT insulation material

Headers, Male Pins Applications

• Industrial control system interconnections
• Consumer electronics assembly
• Telecommunications equipment headers

Headers, Male Pins Procurement Notes

Verify component authenticity against official 3M documentation due to discontinued status. Confirm RoHS compliance and MSL rating before integration. Check for authorized distributors as standard supply chains may be limited. Ensure storage conditions maintain contact integrity prior to soldering.

Headers, Male Pins Selection Notes

Select this model for applications requiring right-angle vertical clearance reduction. The 2.54 mm pitch ensures compatibility with standard PCB layouts. Verify that the 2 A current rating meets circuit requirements. Consider the right-angle form factor for space-constrained designs where vertical stacking is necessary.

Headers, Male Pins Part Context

This component belongs to the 3M 961 series of rectangular connectors. It serves as a male pin header for board-to-board or cable connections. The part number indicates specific physical attributes including position count and termination style within the broader product family.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided data. Due to the discontinued status, direct equivalents must be sourced through engineering validation. Verify mechanical dimensions and electrical ratings carefully when selecting alternative components.
