961230-6804-AR

Headers, Male Pins Overview

The 961230-6804-AR is a vertical pin header connector from the 3M 961 series, designed for through-hole mounting. It features 30 positions in a single row with a 2.54mm (0.100 inch) mating pitch. The contacts are gold-plated on the mating interface and tin-plated on the termination side, housed in black thermoplastic insulation rated UL94 V-0. Rated for 2A at temperatures ranging from -25°C to 105°C, this unshrouded male pin strip utilizes a push-pull locking mechanism and board-to-board style configuration.

Headers, Male Pins Feature Summary

• Vertical board-to-board interconnection design
• Gold-plated mating contacts for reliable signal transmission
• Push-pull locking mechanism for secure attachment
• Thermoplastic insulation with UL94 V-0 flammability rating

Headers, Male Pins Applications

• Board-to-board stacking connections
• General electronic circuit interconnections
• Industrial control panel wiring

Headers, Male Pins Procurement Notes

Verify RoHS compliance status and REACH restrictions before procurement. Confirm that the specific suffix matches the required contact length and plating thickness specifications. Check for obsolescence notices or product change notifications from 3M Electronic Solutions Division. Ensure compatibility with existing PCB footprint designs.

Headers, Male Pins Selection Notes

Select this component when a 30-position vertical header is required. Ensure the mating device supports the 2.54mm pitch and 6.8mm contact length. Verify that the 2A current rating meets the application's electrical requirements. Consider the push-pull locking feature if vibration resistance is necessary.

Headers, Male Pins Part Context

This part belongs to the 3M 961 series of stacking connectors. It is distinct from other variants by its specific 30-position count and 6804-AR suffix indicating particular plating and housing characteristics. It serves as a standard interconnect solution within 3M's broader range of headers and wire housings.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Cross-referencing requires matching exact pin count, pitch, and locking mechanism specifications.
