98424-S52-06LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 98424-S52-06LF is a surface mount header connector from the Minitek series. It features a 2-row, 6-position configuration with a 2.00mm pitch. The component utilizes gold-plated copper alloy contacts and a cream-colored thermoplastic insulator rated UL94 V-0. Designed for board-to-board applications, it offers a shrouded design with a four-wall barrier. The connector supports a maximum current of 2A at 200V AC/DC and operates within a temperature range of -40°C to +125°C.

Headers, Male Pins Feature Summary

• Shrouded four-wall barrier design ensures precise alignment and protection during mating.
• Surface mount termination facilitates automated assembly on printed circuit boards.
• Gold-plated contacts provide reliable electrical performance and corrosion resistance.

Headers, Male Pins Applications

• Board-to-board interconnections
• Industrial instrumentation systems
• Factory automation equipment

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm contact plating thickness and packaging type. Ensure compatibility with standard SMT reflow profiles and check for RoHS compliance status in the latest datasheet before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component for applications requiring a compact 2.00mm pitch header with surface mount termination. Consider the 2-row configuration and shrouded design for improved mechanical stability and pin protection in dense board layouts.

Headers, Male Pins Part Context

This part belongs to the Minitek 2.00mm series by Amphenol ICC (FCI). The series provides versatile interconnect solutions for various electronic assemblies, balancing space constraints with reliable signal transmission capabilities in modern consumer and industrial devices.

Headers, Male Pins Replacement Considerations

Consult official substitution guides for verified equivalents. Cross-referencing requires matching pitch, row count, and mounting style to ensure functional interchangeability without redesigning the footprint.
