99990994

Headers, Male Pins Overview

The Molex 99990994 is a vertical PCB header from the Mini-SPOX series, featuring a 2.50mm pitch and 10 positions. It utilizes through-hole termination with swaged PC tails for secure board mounting. The connector employs tin-plated brass contacts and a natural polyamide (PA66) insulation rated UL94 V-0. Designed for wire-to-board applications, it includes a four-wall shroud to protect mating interfaces.

Headers, Male Pins Feature Summary

• Vertical orientation with single-row configuration for standard PCB layouts
• Four-wall shrouded design ensures precise alignment during mating
• Swaged PC tails provide robust mechanical retention on the circuit board

Headers, Male Pins Applications

• Automotive electronic systems
• Industrial control equipment
• Medical devices
• Telecommunications infrastructure

Headers, Male Pins Procurement Notes

Verify the specific part number against official Molex documentation to confirm current availability and manufacturing status. Ensure that the required pin count and pitch match the design specifications before procurement. Check for any recent product change notices or obsolescence alerts associated with this component series.

Headers, Male Pins Selection Notes

Select this component when a vertical, shrouded header with a 2.50mm pitch is required for wire-to-board connections. The through-hole mounting style suits applications needing high mechanical stability. Confirm that the operating environment aligns with the material ratings and that the 10-position capacity meets the circuit requirements.

Headers, Male Pins Part Context

This component belongs to the Mini-SPOX family of low-profile wire-to-board connectors. The series is engineered for durability in harsh conditions, offering reliable performance across automotive, industrial, and medical sectors. The 99990994 variant specifically provides a fixed 10-position configuration within this standardized interconnect system.

Headers, Male Pins Replacement Considerations

Consult official Molex substitution guides for verified equivalents. Cross-reference pin counts, pitch dimensions, and mounting styles to ensure compatibility. Verify that any alternative maintains the same electrical ratings and mechanical retention characteristics.
