9C24500141

Crystals Overview

The TXC Corporation 9C24500141 is a fundamental frequency crystal resonator operating at 24.576 MHz. It features a load capacitance of 30 pF and an equivalent series resistance (ESR) of 30 Ohms. The component utilizes the HC-49/US through-hole package, ensuring compatibility with standard automated insertion processes. Designed for general-purpose timing applications, it provides stable oscillation within typical industrial temperature ranges.

Crystals Feature Summary

• Provides precise 24.576 MHz fundamental frequency generation
• Utilizes robust HC-49/US through-hole packaging for reliable mounting
• Engineered with 30 pF load capacitance for standard circuit integration

Crystals Applications

• Microcontroller clock source circuits
• Communication interface timing references
• General-purpose digital logic synchronization

Crystals Procurement Notes

Verify the specific tolerance grade and stability specifications against the official manufacturer datasheet prior to procurement. Confirm that the HC-49/US package dimensions align with the target PCB footprint constraints. Ensure the load capacitance requirements match the host oscillator circuit design parameters to guarantee accurate frequency performance.

Crystals Selection Notes

Select this component when a through-hole crystal solution is required for 24.576 MHz applications. Consider the HC-49/US form factor for ease of manual assembly or legacy board designs. Evaluate the 30 Ohm ESR against the driving strength capabilities of the intended oscillator circuit to prevent over-driving or failure to start.

Crystals Part Context

This part belongs to the TXC Corporation 9C series of fundamental mode crystals. These components are widely used in consumer electronics and industrial control systems where cost-effective, reliable timing sources are necessary. The series supports various frequencies and package types to meet diverse design requirements.
