9FGP204BKLF

Overview

The Renesas 9FGP204BKLF is a clock generator integrated circuit designed for Intel CPU server applications. It features a single input and fourteen outputs, supporting a maximum frequency of 400 MHz. The device operates on a supply voltage ranging from 3.135 V to 3.465 V and includes an internal Phase-Locked Loop (PLL). It utilizes a crystal input and provides differential outputs. The component is housed in a 40-VFQFN package with exposed pads, measuring 6 mm by 6 mm. It is rated for operation within a temperature range of 0°C to 70°C.

Feature Summary

• Intel CPU Server Clock/Frequency Generator
• 1 Input to 14 Output Configuration
• Maximum Frequency: 400 MHz
• Internal PLL with Crystal Input
• Differential Outputs Available

Applications

• Intel CPU Server Systems
• High-Performance Computing Platforms
• Server Motherboard Timing Control

Procurement Notes

Verify the specific suffix 'BKL' against official Renesas documentation to confirm pinout compatibility and electrical specifications. Confirm current availability status as this series may have discontinued variants. Ensure the selected packaging matches the required reel or cut-tape quantity for assembly processes.

Selection Notes

Select this component when designing for Intel architecture servers requiring a 1:14 clock distribution ratio. Verify that the system power supply strictly adheres to the 3.135 V to 3.465 V range. Ensure the PCB layout supports the 40-VFQFN package dimensions and thermal requirements for the specified operating temperature range.

Part Context

This part belongs to the 9FGP series of clock generators from Renesas Electronics. These components are specialized for generating precise timing signals for high-speed processors. The 9FGP204 variant specifically targets server environments, providing multiple output clocks derived from a single crystal reference via internal PLL synthesis.

Replacement Considerations

Consult Renesas datasheets for direct cross-references within the 9FGP family. Verify if variants such as 9FGP202 or 9FGP203 offer compatible pinouts or if software configuration differences exist. Do not substitute without verifying electrical parameter alignment.
