9FGV1008CQ500LTGI8

Overview

The 9FGV1008CQ500LTGI8 is a programmable PhiClock generator manufactured by Renesas Electronics. It operates within an industrial temperature range of -40°C to +85°C and accepts a 50 MHz crystal input frequency. The device provides six differential outputs with configurable frequencies including 50 MHz, 100 MHz, 125 MHz, and 156.25 MHz. It supports LP-HCSL and LVDS output signaling types and complies with jitter requirements for PCIe Gen1 through Gen4 applications. The component utilizes a 24-lead LGA package.

Feature Summary

• Programmable clock generation supporting multiple standard frequencies (50/100/125/156.25 MHz)
• Six differential outputs utilizing LP-HCSL or LVDS signaling
• Compliance with PCIe Gen1, Gen2, Gen3, and Gen4 jitter specifications
• Industrial operating temperature range from -40°C to +85°C

Applications

• PCI Express (PCIe) system clock distribution
• Intel CPU server platforms
• SATA interface timing

Procurement Notes

Verify the specific suffix configuration against official Renesas documentation to ensure correct factory settings. Confirm package dimensions and lead count match the 24-lead LGA specification. Check current availability status as manufacturing cycles may vary. Ensure ESD handling procedures are followed during installation.

Selection Notes

Select this component when six synchronized differential clocks are required for high-speed serial interfaces. Verify that the input source matches the 50 MHz crystal requirement. Ensure the target application environment remains within the specified -40°C to +85°C operational limits. Compare power consumption metrics against alternative solutions if thermal management is critical.

Part Context

This part belongs to the 9FGV100xC series of programmable clock generators. It shares architectural similarities with models like the 9FGV1004 and 9FGV1005 but offers specific output counts and configurations tailored for complex multi-lane data transmission systems. The PhiClock branding indicates its optimization for high-performance computing environments.

Replacement Considerations

Direct substitutes include other variants within the 9FGV100xC family such as the 9FGV1004 or 9FGV1005, provided pin compatibility and output requirements align. Verify that any replacement maintains the same jitter performance standards for PCIe compliance.
