A-BL200DG74-022-KSR1

Headers, Receptacles, Female Sockets Overview

The A-BL200DG74-022-KSR1 is a female header receptacle from the A-BL200 series by ASSMANN WSW Components. It features a 2.00 mm pitch and contains 74 positions arranged in a single row. The connector utilizes stamped pin contacts with a female socket configuration, designed for board-to-board applications. It supports through-hole termination and operates within a temperature range of -40°C to +105°C.

Headers, Receptacles, Female Sockets Feature Summary

• Female socket contact type utilizing stamped pin construction for reliable mating
• Single row receptacle design optimized for board-to-board interconnection
• Through-hole termination method ensuring secure PCB mounting

Headers, Receptacles, Female Sockets Applications

• Board-to-board electrical interconnections
• High-density circuit module assembly
• Industrial control system interfaces

Headers, Receptacles, Female Sockets Procurement Notes

Verify the exact position count of 74 and the 2.00 mm pitch against schematic requirements. Confirm that the female socket orientation matches the mating header polarity. Ensure the through-hole footprint aligns with the PCB layout specifications before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a high-pin-count female receptacle is required for direct board-to-board connection. The 2.00 mm pitch allows for denser packing compared to standard 2.54 mm headers. Consider the stamped pin construction for cost-effective mass production needs while maintaining adequate mechanical stability.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the A-BL200 series, which focuses on compact female headers with a 2.00 mm pitch. ASSMANN WSW Components specializes in such connectors for flat cable and board-to-board applications. The series offers various position counts to accommodate different signal routing densities.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other 2.00 mm pitch female headers with 74 positions, such as the A-BL200DG76-022-KSR1 variant, provided the physical dimensions and contact configuration remain identical.
