A-WBP-K001EA-05TB02

Headers, Male Pins Overview

The A-WBP-K001EA-05TB02 is a rectangular connector header manufactured by Assmann WSW Components. It features a through-hole mounting style with a right-angle configuration, designed for wire-to-board applications. The component provides five positions with a pitch of 0.079 inches (2.00mm). Constructed as a wafer-style connector, it utilizes nickel-plated pins and an insulator to ensure reliable electrical connectivity in standard electronic assemblies.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting design for PCB integration
• Five-position layout with 2.00mm pitch spacing
• Wafer-style rectangular header construction

Headers, Male Pins Applications

• Wire-to-board interconnections
• General electronic circuit assembly
• PCB header connections

Headers, Male Pins Procurement Notes

Verify the specific pin count and pitch against project requirements before ordering. Confirm that the right-angle orientation matches the board layout constraints. Ensure compatibility with mating connectors from the same series or compatible wafer systems. Check surface finish specifications if corrosion resistance is critical for the intended environment.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle connection is required for five wires. The 2.00mm pitch offers a balance between density and ease of handling. Consider the through-hole method for robust mechanical stability compared to surface mount alternatives. Evaluate space limitations on the PCB to accommodate the right-angle profile height.

Headers, Male Pins Part Context

This part belongs to the A-WBP-K001EA series of rectangular headers from Assmann WSW Components. The series typically includes various pin counts and configurations, such as 9-pin variants like the A-WBP-K001EA-09TB02. These components are designed for standardized connectivity solutions within the company's broader portfolio of IDC and flat cable accessories.

Headers, Male Pins Replacement Considerations

Compatible substitutes may include other 5-position, 2.00mm pitch right-angle headers from different manufacturers. Ensure the replacement maintains the same through-hole mounting style and current/voltage ratings. Verify physical dimensions to guarantee fit within the existing enclosure or PCB footprint.
