A-WBP-O001DG-10SR01

A-WBP-O001DG-10SR01 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Assmann WSW Components. Its product description is WIRE-TO-BOARD, WAFER, 3.00MM, 10. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A-WBP-O001DG-10SR01

• Description：WIRE-TO-BOARD, WAFER, 3.00MM, 10
• Series：A-WBP
• Mfr：Assmann WSW Components
• Package：Tape & Reel (TR)
• Connector Type：Header
• Contact Type：Male Pin
• Pitch - Mating：0.118" (3.00mm)
• Number of Positions：10
• Number of Rows：2
• Row Spacing - Mating：0.118" (3.00mm)
• Number of Positions Loaded：All
• Style：Board to Board
• Shrouding：Shrouded - 4 Wall
• Mounting Type：Surface Mount
• Termination：Solder
• Fastening Type：Locking Ramp
• Contact Length - Mating：-
• Contact Length - Post：-
• Overall Contact Length：-
• Insulation Height：0.390" (9.91mm)
• Contact Shape：Square
• Contact Finish - Mating：Tin
• Contact Finish Thickness - Mating：-
• Contact Finish - Post：Tin
• Contact Material：Brass
• Insulation Material：Liquid Crystal Polymer (LCP)
• Features：Solder Retention
• Operating Temperature：-25°C ~ 85°C
• Ingress Protection：-
• Material Flammability Rating：UL94 V-0
• Insulation Color：Black
• Current Rating (Amps)：5A
• Voltage Rating：250VAC/DC

Headers, Male Pins datasheet and documents for A-WBP-O001DG-10SR01
