A-WBP-S001DG-06TP02

A-WBP-S001DG-06TP02 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Assmann WSW Components. Its product description is WIRE-TO-BOARD, WAFER, 4.20MM, 6P. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A-WBP-S001DG-06TP02

• Description：WIRE-TO-BOARD, WAFER, 4.20MM, 6P
• Series：A-WBP
• Mfr：Assmann WSW Components
• Package：Tray
• Connector Type：Header
• Contact Type：Male Pin
• Pitch - Mating：0.165" (4.20mm)
• Number of Positions：6
• Number of Rows：2
• Row Spacing - Mating：0.165" (4.20mm)
• Number of Positions Loaded：All
• Style：Board to Cable/Wire
• Shrouding：Shrouded - 4 Wall
• Mounting Type：Through Hole
• Termination：Solder
• Fastening Type：Locking Ramp
• Contact Length - Mating：-
• Contact Length - Post：0.134" (3.40mm)
• Overall Contact Length：-
• Insulation Height：0.506" (12.85mm)
• Contact Shape：Rectangular
• Contact Finish - Mating：Tin
• Contact Finish Thickness - Mating：-
• Contact Finish - Post：-
• Contact Material：Brass
• Insulation Material：Polyamide (PA66), Nylon 6/6
• Features：-
• Operating Temperature：-25°C ~ 85°C
• Ingress Protection：-
• Material Flammability Rating：UL94 V-0
• Insulation Color：Natural
• Current Rating (Amps)：7A (AC/DC)
• Voltage Rating：600VAC/DC

Headers, Male Pins datasheet and documents for A-WBP-S001DG-06TP02
