A1-16PA-2.54DS(71)

Headers, Male Pins Overview

The A1-16PA-2.54DS(71) is a board-to-board header connector from the Hirose A1 series, designed for high-density interconnections. It features a 2.54 mm pitch with 16 positions arranged in a dual-row configuration. The component utilizes gold-plated contacts and a right-angle through-hole mounting style, ensuring reliable signal transmission in compact electronic assemblies.

Headers, Male Pins Feature Summary

• High-density dual-row layout for space-constrained applications
• Right-angle orientation facilitates efficient PCB routing
• Gold contact plating ensures durable electrical performance

Headers, Male Pins Applications

• Compact consumer electronics modules
• Industrial control system interfaces
• Telecommunications equipment backplanes

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix (71) to confirm packaging and compliance details. Check current availability status as distribution channels may vary. Ensure compatibility with mating receptacles within the same A1 series family before procurement.

Headers, Male Pins Selection Notes

Select this part when a 2.54 mm pitch right-angle header is required. Confirm that the 16-position count matches the circuit design. Verify that the through-hole mounting method aligns with the PCB manufacturing capabilities and mechanical constraints of the assembly.

Headers, Male Pins Part Context

This component belongs to the Hirose A1 series, which specializes in high-density board-to-board connectors. The series is engineered for applications requiring robust connections in limited spaces, offering various pin counts and orientations to support diverse electronic design requirements.

Headers, Male Pins Replacement Considerations

Compatible substitutes include other Hirose A1 series headers with matching 2.54 mm pitch and 16-pin configurations. Verify mechanical dimensions and contact plating specifications to ensure interchangeability without redesigning the PCB footprint.
