A25002-004

Headers, Receptacles, Female Sockets Overview

The Omnetics A25002-004 is a 4-position surface mount receptacle connector from the Micro Strip series. It features female sockets with a 0.050-inch (1.27mm) pitch and right-angle orientation. The contacts are gold-plated for reliable signal transmission. Designed for free-hanging installation, this component utilizes pin-lock fastening to secure mating connections. It supports discrete wire termination via cup-style soldering, ensuring robust mechanical attachment in compact electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount right-angle receptacle design
• Gold-plated female socket contacts
• Pin-lock fastening mechanism
• Cup-style solder termination

Headers, Receptacles, Female Sockets Applications

• Compact electronic device interconnects
• High-density circuit board assemblies
• Right-angle signal routing applications

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against official Omnetics documentation to confirm exact contact count and termination style. Ensure compatibility with mating header components within the same Micro Strip series. Check for RoHS compliance status if required by project specifications, as some variants may not meet current environmental standards. Confirm package quantity details directly with the supplier prior to order placement.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, right-angle surface mount solution is required for high-reliability applications. The 0.050-inch pitch allows for dense packing while maintaining adequate spacing. The pin-lock feature provides enhanced security against accidental disconnection compared to friction-fit alternatives. Ideal for space-constrained environments where vertical clearance is limited but horizontal mounting is feasible.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Omnetics Micro Strip family, known for miniature connectors. It complements related products like the A24001-004 male header. The series emphasizes small form factors and high reliability. The A25002-004 specifically addresses needs for surface-mounted female connections with secure locking mechanisms in modern electronics manufacturing.

Headers, Receptacles, Female Sockets Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires matching pitch, contact count, and mounting style. Verify mechanical dimensions and electrical ratings before considering alternative manufacturers.
