A25202-012

Headers, Receptacles, Female Sockets Overview

The Omnetics A25202-012 is a Micro Strip series receptacle connector designed for surface mount applications. It features 12 positions with female contacts arranged in a single row. The connector utilizes a 0.050 inch (1.27mm) mating pitch and employs a push-pull locking mechanism for secure attachment. Contacts are gold-plated to ensure reliable signal transmission. The housing is constructed from black insulating material, suitable for board-to-board interconnections.

Headers, Receptacles, Female Sockets Feature Summary

• Surface mount design for automated PCB assembly
• Push-pull locking system for secure mating
• Gold-plated female contacts for conductivity

Headers, Receptacles, Female Sockets Applications

• Board-to-board interconnections
• High-reliability electronic systems
• Compact consumer electronics assemblies

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number suffix against official Omnetics documentation to confirm exact contact plating thickness and housing material specifications. Ensure compatibility with mating male connectors within the same Micro Strip series. Confirm surface mount footprint dimensions match the target PCB layout before procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, surface-mount solution is required for 12-channel interconnects. The 0.050-inch pitch allows for dense circuit layouts. Consider the push-pull retention requirement versus other locking styles available in the Micro Strip family. Evaluate thermal performance requirements against the specified operating temperature range.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Omnetics Micro Strip series, which specializes in high-density rectangular connectors. The series is engineered for mission-critical applications requiring robust performance in compact form factors. The A25202-012 represents a standard receptacle configuration within this lineup, offering consistent electrical characteristics across the product family.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible mating parts include male headers from the same Micro Strip series, such as A24201-012 or A24202-012. Verify pin count and pitch alignment when substituting. Cross-series replacements require careful evaluation of mechanical interface and electrical ratings.
