A25202-016

Headers, Receptacles, Female Sockets Overview

The Omnetics A25202-016 is a Micro Strip series receptacle connector featuring 16 positions with female socket contacts. It utilizes a 0.050 inch (1.27mm) pitch and is designed for surface mount, right-angle termination. The connector employs a push-pull locking mechanism and gold-plated contacts to ensure reliable signal transmission in board-to-board applications.

Headers, Receptacles, Female Sockets Feature Summary

• Micro Strip series design for high-density interconnects
• Push-pull locking mechanism for secure mating
• Gold-plated contacts for corrosion resistance

Headers, Receptacles, Female Sockets Applications

• Board-to-board connections
• High-reliability electronic assemblies
• Miniature interconnect systems

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific part number against official Omnetics documentation to confirm compatibility with mating headers. Ensure that the surface mount footprint and right-angle orientation match the target PCB layout requirements before procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a compact, high-reliability receptacle with a push-pull lock is required. The Micro Strip series offers robust performance in space-constrained environments, suitable for applications demanding consistent electrical characteristics over repeated mating cycles.

Headers, Receptacles, Female Sockets Part Context

Omnetics specializes in micro-miniature connectors known for mission-critical reliability. The A25202-016 belongs to the Micro Strip family, which provides flexible pin technology designed for extensive mating durability and stable operation across wide temperature ranges.

Headers, Receptacles, Female Sockets Replacement Considerations

Consult official Omnetics substitution guides for verified alternatives. Generic rectangular connectors may not replicate the specific push-pull locking or flex-pin interface characteristics of the Micro Strip series.
