A25204-012

Headers, Receptacles, Female Sockets Overview

The Omnetics A25204-012 is a Micro Strip series rectangular receptacle connector featuring 12 positions. It utilizes a 0.050 inch (1.27mm) pitch with dual rows and through-hole termination. The contacts are female sockets with gold plating, housed in black insulating material. Designed for board-to-board applications, it offers reliable interconnectivity in compact electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

• Micro Strip series design for high-density board-to-board connections
• Dual-row configuration with 0.050 inch centerline spacing
• Through-hole termination for secure PCB mounting
• Gold-plated female socket contacts for corrosion resistance

Headers, Receptacles, Female Sockets Applications

• Compact electronic device interconnects
• Board-to-board signal transmission
• High-density circuit assembly integration

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific datasheet version to confirm pinout orientation and mechanical dimensions. Ensure compatibility with mating header connectors regarding row alignment and contact type. Check for any specific handling requirements during surface mount or through-hole assembly processes.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a dual-row, 12-position through-hole receptacle is required. The 0.050 inch pitch suits space-constrained designs needing robust female socket connections. Consider the black housing color and gold contact finish for environmental durability and conductivity needs.

Headers, Receptacles, Female Sockets Part Context

Part of the Omnetics Micro Strip family, known for micro-miniature precision connectors. This series targets demanding industries like aerospace and medical devices where reliability and small form factors are critical. The A25204-012 represents a standard through-hole variant within this rugged portfolio.

Headers, Receptacles, Female Sockets Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model. Evaluate other Omnetics Micro Strip receptacles with matching 12-position, dual-row, and 0.050 inch pitch specifications if substitution is necessary.
