A25204-040

Headers, Receptacles, Female Sockets Overview

The Omnetics A25204-040 is a Micro Strip series receptacle connector featuring 40 positions in a dual-row configuration. It utilizes a 0.050 inch (1.27mm) contact spacing and is designed for through-hole termination. The female socket contacts are gold-plated to ensure reliable signal transmission. This component serves as a high-reliability interconnect solution within the Micro Strip family, engineered for precision mounting in compact electronic assemblies.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row receptacle architecture with 40 female socket contacts
• Through-hole vertical mounting for stable board integration
• Gold-plated contact surfaces for enhanced conductivity
• Micro Strip series design optimized for micro-miniature applications

Headers, Receptacles, Female Sockets Applications

• High-reliability military and aerospace electronic systems
• Medical device interconnects requiring precise signal routing
• Aviation avionics and navigation equipment modules
• Compact unmanned system control units

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to confirm exact termination style and plating specifications. Ensure compatibility with mating header components from the same Micro Strip series. Confirm that the through-hole footprint matches the target PCB layout dimensions prior to procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this part when a 40-position dual-row interface is required with through-hole assembly capabilities. The 0.050-inch pitch accommodates standard micro-interconnect densities. Consider the gold plating for corrosion resistance in demanding environments. Validate mechanical retention requirements against the pin-lock or push-pull features available in the broader series.

Headers, Receptacles, Female Sockets Part Context

This component belongs to the Omnetics Micro Strip family, which specializes in high-reliability micro-miniature connectors. The series is characterized by rugged Flex-Pin contact systems and is manufactured in the United States. These connectors are engineered for mission-critical applications where space constraints and performance stability are paramount.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible mating headers include A24204-040 (through-hole), A24201-040 (surface mount right-angle), and A24202-040 (surface mount). Verify pin count and pitch alignment when substituting with other 40-position variants in the Micro Strip line.
