A25204-044

Headers, Receptacles, Female Sockets Overview

The A25204-044 is a Micro Strip series receptacle connector manufactured by Omnetics. It features 44 positions with female socket contacts arranged in a dual-row configuration. The connector utilizes a 0.050 inch (1.27 mm) centerline spacing and is designed for through-hole vertical mounting on printed circuit boards. Contacts are gold-plated to ensure reliable signal transmission. This component serves as the mating counterpart to male pin headers within the Micro Strip interconnect system.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row receptacle design accommodating 44 contact positions
• Gold-plated female socket contacts for high-reliability connections
• Through-hole vertical termination method for PCB integration
• 0.050 inch (1.27 mm) centerline spacing for compact board layout

Headers, Receptacles, Female Sockets Applications

• High-density electronic interconnect systems
• Board-to-board connection modules
• Military and aerospace avionics assemblies
• Medical device internal wiring harnesses

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific part number matches the required 44-position count and dual-row configuration before ordering. Confirm that the manufacturing origin aligns with project requirements, as Omnetics products are produced in the United States. Ensure compatibility with the corresponding male header series, specifically checking for matching pitch and locking mechanisms. Review datasheet specifications for thermal and electrical ratings to confirm suitability for the intended operational environment.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a high-pin-count, dual-row interface is necessary for space-constrained applications. The through-hole mounting style provides robust mechanical stability compared to surface-mount alternatives. Consider the gold plating for environments requiring corrosion resistance and low contact impedance. Ensure the mating partner is a compatible Micro Strip male header with identical 0.050-inch spacing to guarantee proper alignment and engagement.

Headers, Receptacles, Female Sockets Part Context

This connector belongs to the Micro Strip family, which specializes in micro-miniature rectangular interconnects. The series is engineered for high reliability in demanding sectors such as defense and aviation. Components in this line typically feature ruggedized contacts and precise dimensional tolerances to maintain performance under vibration and shock. The A25204-044 represents a high-density variant within this portfolio.
