A79026-001

$69.44

Description：36 POSITION DUAL ROW MALE NANO-M
Series：Nano Strip
Mfr：Omnetics
Package：Bag

SKU:ac05e0f5aa1a Category: Headers, Male Pins Brand: Omnetics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

A79026-001 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Omnetics. Its product description is 36 POSITION DUAL ROW MALE NANO-M. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A79026-001

Description：36 POSITION DUAL ROW MALE NANO-M
Series：Nano Strip
Mfr：Omnetics
Package：Bag
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.025" (0.64mm)
Number of Positions：36
Number of Rows：2
Row Spacing - Mating：0.030" (0.76mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：Shrouded - 4 Wall
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：-
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.173" (4.40mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：50.0µin (1.27µm)
Contact Finish - Post：Tin-Lead
Contact Material：Beryllium Copper
Insulation Material：Thermoplastic
Features：Guide Pin
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Natural
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for A79026-001

A79026-001

Headers, Male Pins Overview

The Omnetics A79026-001 is a 36-position dual-row male Nano Strip connector designed for surface mount technology. It features a 0.025-inch (0.64 mm) mating pitch and utilizes push-pull retention mechanisms. The connector includes four guide holes for precise alignment during assembly. Contacts are gold-plated with a thickness of 50.0 µin (1.27 µm), ensuring reliable signal transmission. The unit operates within a temperature range of -55°C to +125°C and supports a rated current of 1A per contact.

Headers, Male Pins Feature Summary

Surface mount design with integrated guide holes for accurate PCB placement
Push-pull locking system ensures secure mechanical connection
Gold-plated contacts provide corrosion resistance and low contact impedance

Headers, Male Pins Applications

Neuroscience research instrumentation
Precision medical devices
High-density electronic interconnects

Headers, Male Pins Procurement Notes

Verify the specific part number against official Omnetics documentation to confirm compatibility with mating connectors. Ensure that the surface mount footprint matches the design specifications. Check for RoHS compliance status if required by project regulations. Confirm lead times directly with authorized distributors as manufacturing schedules may vary.

Headers, Male Pins Selection Notes

Select this component when high-density board-to-board or board-to-cable connections are required in space-constrained applications. The dual-row configuration maximizes pin count within a minimal footprint. Consider the push-pull mechanism if frequent disconnection and reconnection cycles are anticipated. Verify thermal requirements against the specified operating temperature range.

Headers, Male Pins Part Context

This component belongs to the Nano Strip series, which provides precision interconnect solutions for demanding environments. The series is known for its small form factor and reliability in scientific and medical applications. The A79026-001 variant specifically offers a 36-pin configuration suitable for complex signal routing needs.
