A79039-001

$89.11

Description：NANO 18 SKT FEMALE PCB W/ 2 GUID
Series：Nano Strip
Mfr：Omnetics
Package：Case

SKU:28644ca21267 Category: Headers, Receptacles, Female Sockets Brand: Omnetics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

A79039-001 is listed in the Headers, Receptacles, Female Sockets range at ChipApex. The manufacturer field lists Omnetics. Its product description is NANO 18 SKT FEMALE PCB W/ 2 GUID. Review the specifications below when checking this part for your BOM.

Headers, Receptacles, Female Sockets specifications for A79039-001

Description：NANO 18 SKT FEMALE PCB W/ 2 GUID
Series：Nano Strip
Mfr：Omnetics
Package：Case
Connector Type：Receptacle
Contact Type：Female Socket
Style：Board to Board
Number of Positions：18
Number of Positions Loaded：All
Pitch - Mating：0.025" (0.64mm)
Number of Rows：2
Row Spacing - Mating：0.030" (0.76mm)
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：50.0µin (1.27µm)
Insulation Color：Natural
Insulation Height：0.070" (1.78mm)
Contact Length - Post：0.100" (2.54mm)
Operating Temperature：-55°C ~ 125°C
Material Flammability Rating：-
Contact Finish - Post：Tin-Lead
Mated Stacking Heights：-
Ingress Protection：-
Features：Guide Pin
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Receptacles, Female Sockets datasheet and documents for A79039-001

A79039-001

Headers, Receptacles, Female Sockets Overview

The Omnetics A79039-001 is an 18-position receptacle connector from the Nano Strip series, designed for through-hole vertical mounting. It features a 0.025-inch (0.64mm) contact spacing and dual rows with a 0.030-inch (0.76mm) row pitch. The connector utilizes gold-plated contacts with a 50.0µin thickness and operates within a temperature range of -55°C to 125°C. Rated at 1A per contact, it includes two guide pins for precise alignment and employs a push-pull locking mechanism.

Headers, Receptacles, Female Sockets Feature Summary

Push-pull locking mechanism ensures secure mating
Integrated guide pins facilitate precise alignment
Gold-plated contacts provide reliable conductivity

Headers, Receptacles, Female Sockets Applications

Precision interconnect systems
Neuroscience research equipment
High-density board-to-board connections

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix codes against official Omnetics documentation to confirm exact pin configuration and guide pin count. Ensure compatibility with mating header specifications regarding current ratings and thermal limits. Cross-reference datasheets for mechanical dimensions to validate PCB footprint requirements before procurement.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when through-hole vertical mounting is required for high-density applications. The Nano Strip series offers precision engineering suitable for sensitive environments. Consider the push-pull locking style for ease of assembly and maintenance compared to screw-lock alternatives.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Nano Strip series, known for precision connectors used in demanding fields like neuroscience research. The series provides various configurations including surface mount and through-hole options with different pin counts and locking styles.
