A79041-001

Headers, Receptacles, Female Sockets Overview

The Omnetics A79041-001 is a 18-position female receptacle connector from the Nano Strip series, designed for surface mount installation. It features a 0.025-inch (0.64mm) contact pitch and right-angle termination. The connector utilizes gold-plated contacts with a 50.0µin thickness and operates within a temperature range of -55°C to 125°C. Rated at 1A per contact, it includes guide pins for precise alignment and employs a push-pull locking mechanism.

Headers, Receptacles, Female Sockets Feature Summary

• Right-angle surface mount design for compact board integration
• Integrated guide pins ensure accurate mating alignment
• Push-pull locking mechanism provides secure connection retention

Headers, Receptacles, Female Sockets Applications

• High-density electronic assemblies requiring precise alignment
• Board-to-board interconnections in space-constrained environments
• Applications demanding reliable signal transmission under thermal stress

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific suffix codes against the manufacturer's official documentation to confirm exact pin configuration and plating specifications. Ensure compatibility with mating male connectors regarding the push-pull locking interface and guide pin placement. Confirm that the surface mount footprint matches the target PCB design requirements before finalizing procurement orders.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a right-angle female receptacle with integrated guidance is required for surface mounting. The 18-position count and 0.025-inch pitch suit high-density applications. Consider the push-pull locking feature if vibration resistance is critical. Verify that the operating temperature range meets the environmental conditions of the intended deployment scenario.

Headers, Receptacles, Female Sockets Part Context

This part belongs to the Nano Strip series by Omnetics, known for precision connectors used in demanding fields such as neuroscience research. The series offers various configurations including polarized and standard options, catering to diverse interconnection needs with consistent quality standards across the product line.

Headers, Receptacles, Female Sockets Replacement Considerations

A79017-001 is listed as a parameter equivalent alternative.
