A79608-001

$60.49

Description：NANO 6POS MALE/FEMALE POLARIZED
Series：Polarized Nano
Mfr：Omnetics
Package：Bag

SKU:46f9fd3bffbe Category: Headers, Male Pins Brand: Omnetics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

A79608-001 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Omnetics. Its product description is NANO 6POS MALE/FEMALE POLARIZED. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for A79608-001

Description：NANO 6POS MALE/FEMALE POLARIZED
Series：Polarized Nano
Mfr：Omnetics
Package：Bag
Connector Type：Header
Contact Type：Female Socket; Male Pin
Pitch - Mating：0.025" (0.64mm)
Number of Positions：6
Number of Rows：2
Row Spacing - Mating：0.040" (1.02mm)
Number of Positions Loaded：All
Style：Board to Cable/Wire
Shrouding：-
Mounting Type：Surface Mount, Right Angle
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.060" (1.52mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.080" (2.03mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：50.0µin (1.27µm)
Contact Finish - Post：Tin-Lead
Contact Material：Beryllium Copper
Insulation Material：Thermoplastic
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：-
Insulation Color：Natural
Current Rating (Amps)：1A per Contact
Voltage Rating：-

Headers, Male Pins datasheet and documents for A79608-001

A79608-001

Headers, Male Pins Overview

The Omnetics A79608-001 is a Polarized Nano (PZN) series connector featuring 6 positions in a 2-row configuration. It utilizes a 0.025-inch (0.64mm) pitch with a 0.040-inch (1.02mm) row spacing. Designed for surface mount, right-angle installation, it combines female and male contacts within a single housing to achieve polarization without guide pins. The connector supports a rated current of 1A per contact and operates between -55°C and 125°C.

Headers, Male Pins Feature Summary

Integrated male and female contacts enable internal polarization, eliminating the need for external guide pins while maintaining compact form factors.
Surface mount right-angle termination facilitates efficient board space utilization in dense electronic assemblies.
Gold-plated mating surfaces ensure reliable electrical conductivity and corrosion resistance in demanding environments.

Headers, Male Pins Applications

High-density board-to-board interconnections
Space-constrained aerospace systems
Precision medical instrumentation

Headers, Male Pins Procurement Notes

Verify that the specific application environment accommodates the non-RoHS compliant status of this component. Confirm that the mixed male/female contact configuration aligns with the mating interface requirements. Ensure the surface mount footprint matches the specified right-angle dimensions to guarantee proper mechanical retention during soldering processes.

Headers, Male Pins Selection Notes

Select this model when polarization is required but guide pin space is unavailable. The mixed-contact design simplifies assembly by preventing misalignment. Consider the 1A current rating and thermal range to ensure compatibility with system power and operating conditions. Verify that the surface mount process supports the right-angle orientation constraints.

Headers, Male Pins Part Context

This component belongs to the Polarized Nano series, designed for applications requiring high reliability in minimal space. The series emphasizes precision engineering for harsh environments. The A79608-001 variant specifically addresses the need for secure connections without additional alignment hardware.
