A79613-001

Headers, Male Pins Overview

The Omnetics A79613-001 is a Polarized Nano (PZN) series rectangular connector designed for board-to-cable or wire connections. It features an 8-position configuration with male pin and female socket contacts, arranged in a single row. The connector utilizes a horizontal surface mount termination style with a 0.025-inch (0.64mm) contact spacing. Rated for 1A per contact, it operates within a temperature range of -55°C to 125°C. The housing is made of natural thermoplastic insulation, while contacts are gold-plated copper alloy.

Headers, Male Pins Feature Summary

• Polarized design prevents misalignment during mating
• Compact surface mount footprint for space-constrained applications
• Gold-plated contacts ensure reliable signal transmission
• Push-pull locking mechanism for secure connection

Headers, Male Pins Applications

• Compact electronic devices requiring board-to-wire interconnects
• Neuroscience research equipment precision connectors
• High-density circuit board assemblies
• Automotive control modules
• Medical instrumentation interfaces

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix matches the required contact length and orientation. Confirm that the polarized keying aligns with the mating cable assembly. Ensure the surface mount pad layout corresponds to the manufacturer's recommended land pattern. Check for any special handling requirements due to the small form factor. Validate that the current rating meets the application's electrical load demands.

Headers, Male Pins Selection Notes

Choose this component when a low-profile, polarized solution is needed for 8-way interconnections. Consider the 0.025-inch pitch for high-density routing. Evaluate the thermal performance against the operating environment limits. Compare against similar PZN series variants for different row counts or termination styles. Ensure compatibility with existing PCB fabrication capabilities for fine-pitch SMT.

Headers, Male Pins Part Context

This part belongs to the Polarized Nano (PZN) series by Omnetics, known for precision miniaturization. The series supports various configurations including straight and right-angle headers. It is widely used in applications demanding reliable, small-footprint connectivity. The A79613-001 specifically addresses the need for 8-position board-to-cable solutions.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Omnetics PZN series parts with matching pin counts and polarization. Verify mechanical dimensions and electrical ratings before substitution. Cross-reference with equivalent connectors from other manufacturers only if form-fit-function data is confirmed.
