A79617-001

Headers, Male Pins Overview

The Omnetics A79617-001 is a Polarized Nano (PZN) series board-to-board connector featuring 10 positions in a single row. It utilizes vertical surface mount termination with a 0.025-inch (0.64mm) mating pitch and 0.040-inch (1.02mm) row spacing. The connector supports male and female polarized interfaces, employing circular contacts made of platinum copper alloy with gold plating on mating surfaces. Rated for 1A per contact, it operates within a temperature range of -55°C to 125°C.

Headers, Male Pins Feature Summary

• Features a polarized design to ensure correct alignment during mating
• Utilizes gold-plated contacts to prevent oxidation issues common in bare copper connectors
• Supports vertical surface mount installation for compact board-to-board applications

Headers, Male Pins Applications

• Neuroscience research instrumentation
• Precision electronic interconnect systems
• Compact board-to-board signal transmission

Headers, Male Pins Procurement Notes

Verify the specific part number against official Omnetics documentation to confirm pin count and polarization orientation. Ensure compatibility with mating components from the same PZN series. Check for updated datasheets regarding material specifications and thermal ratings before integration into final designs.

Headers, Male Pins Selection Notes

Select this component when a low-profile, polarized solution is required for high-reliability connections. The single-row configuration suits space-constrained layouts. Verify that the mating connector matches the 10-position requirement and compatible pitch dimensions to ensure proper mechanical and electrical engagement.

Headers, Male Pins Part Context

This connector belongs to the Polarized Nano (PZN) series by Omnetics, designed for precision applications. The series emphasizes reliability through polarized locking mechanisms and corrosion-resistant contact plating. It serves as a specialized interconnect solution for industries requiring robust performance in small form factors.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Users should consult Omnetics directly for alternative options or cross-reference with other PZN series variants if pin counts differ.
